The Physical Properties of Water
3 min read · Energy Atlas Editorial
Water is a chemical compound made from one oxygen and two hydrogen atoms. At normal conditions, it is a colourless, clear, and odourless liquid.
Molecule of water
Water is a chemical compound made of hydrogen and oxygen.
At room temperature and atmospheric pressure, it is a colourless, clear and odourless liquid.
In nature, it is found in three states:
- solid — ice and snow
- liquid — water
- gas — water vapour
Molar mass · 18.01528 g/mol Melting temperature · 0 °C (at atmospheric pressure) Boiling temperature · 100 °C (at atmospheric pressure) Density · 0.99997 g/cm³ (at 3.98 °C) Viscosity · 0.001 Pa·s (at 20 °C) Refraction index · 1.33 Critical temperature · 373.95 °C Critical pressure · 22.064 MPa Surface tension · 0.073 N/m (20 °C) Sound velocity, roughly · 1,460 m/s Specific heat coefficient · 4,184 J/(kg·K) (liquid water at 20 °C)
